The original Heavy Duty Cooler Kart Frame

Made in USA

Heavy duty cooler kart frame built with 1x1x14 gauge square tube

Engineered for easy assembly

Accepts up to a 18 HP engine

Cooler and riders combined capacity up to 400 lbs.

Compatible with clutch or torque converter

Cooler length up to 40" long

3/4" jack shaft mount (optional)

3 bolt bearing hangers for 1" live axle

 Footpeg locations are determined by customer

Upper & lower adjustable steering shaft mounts

Heavy duty 1/4" thick motor mount

Steering shaft support can be mounted with brace forward or rearward

Optional ball mount and weelie bars (designed for skateboard wheels)

10" disc brake caliper mount

Jig welded

Square tube end caps for installation after painting is completed

AWS certified

Frame will be new unpainted steel (may have some surface rust)

Approximately 7"x 24"x 64" ( 70lbs.)

Some drilling required

Parts included: main frame, 2 sets of foot peg mounts, adjustable jackshaft mounts, upper/lower steering shaft mount tubes, steering shaft support, tube end caps
